STM32F103ZGT6 MCU Microcontroller Unit ARM Cortex M3 32Bit 1Mbyte Flash 72MHz

STM32F103ZGT6 Arm Microcontrollers MCU ARM Cortex M3 32-Bit 1Mbyte Flash 72 MHz

Specifications

Description

XL-density performance line ARM®-based 32-bit MCU with 768 KB to 1 MB Flash, USB, CAN, 17 timers, 3 ADCs, 13 com. interfaces

The STM32F103xF and STM32F103xG performance line family incorporates the highperformance ARM® Cortex®-M3 32-bit RISC core operating at a 72 MHz frequency, highspeed embedded memories (Flash memory up to 1 Mbyte and SRAM up to 96 Kbytes), and an extensive range of enhanced I/Os and peripherals connected to two APB buses. All devices offer three 12-bit ADCs, ten general-purpose 16-bit timers plus two PWM timers, as well as standard and advanced communication interfaces: up to two I2Cs, three SPIs, two I 2Ss, one SDIO, five USARTs, an USB and a CAN.

The STM32F103xF/G XL-density performance line family operates in the –40 to +105 °C temperature range, from a 2.0 to 3.6 V power supply. A comprehensive set of power-saving mode allows the design of low-power applications.

Features

• Core: ARM® 32-bit Cortex®-M3 CPU with MPU – 72 MHz maximum frequency, 1.25 DMIPS/MHz (Dhrystone 2.1) performance at 0 wait state memory access – Single-cycle multiplication and hardware division

• Memories

– 768 Kbytes to 1 Mbyte of Flash memory

– 96 Kbytes of SRAM

– Flexible static memory controller with 4 Chip Select. Supports Compact Flash, SRAM, PSRAM, NOR and NAND memories

– LCD parallel interface, 8080/6800 modes

• Clock, reset and supply management

– 2.0 to 3.6 V application supply and I/Os

– POR, PDR, and programmable voltage detector (PVD)

– 4-to-16 MHz crystal oscillator

– Internal 8 MHz factory-trimmed RC

– Internal 40 kHz RC with calibration

– 32 kHz oscillator for RTC with calibration

• Low power

– Sleep, Stop and Standby modes

– VBAT supply for RTC and backup registers

• 3 × 12-bit, 1 µs A/D converters (up to 21 channels)

– Conversion range: 0 to 3.6 V

– Triple-sample and hold capability

– Temperature sensor

• 2 × 12-bit D/A converters

• DMA: 12-channel DMA controller

– Supported peripherals: timers, ADCs, DAC, SDIO, I2Ss, SPIs, I2Cs and USARTs

• Debug mode

Applications

These features make the STM32F103xF/G high-density performance line microcontroller family suitable for a wide range of applications such as motor drives, application control, medical and handheld equipment, PC and gaming peripherals, GPS platforms, industrial applications, PLCs, inverters, printers, scanners, alarm systems and video intercom.
